Carbon Fiber Plate
Pultruded Carbon Fiber Plate

Carbon Fiber Plate

Carbon fiber plates(CFRP plates \CFRP strip) is produced by special resin and 12K \ 24K high strength carbon fiber.
Product Detail

Pultruded carbon fiber profiles is to use resin impregnated continuous fiber bundle, belt or cloth to produce the composite material with the same cross-sectional shape and infinite length by die extrusion forming and curing continuously.

Resin: Epoxy, vinyl, polyurethane.


Main features:

Low density, light weight: density is only 1/5 of steel.

High strength and elastic modulus and excellent impact resistance: tensile strength is 8-10 times of steel, and elasticity can recover to 100%.

Excellent corrosion resistance, low long-term creep.

Excellent fatigue resistance.

Fully automated production, high efficiency .

80% Fiber content enables very high strength.

Less waste, save labor, materials and energy.

Stable quality and good repeatability. Any length is theoretically available.


Specification Table

Cross sectionSize(mm)
Plate .jpg


Plate


W

T

20

10.8

40.3

10.6

44

13.8

50

2

50

3

80

3

68

2

88

5

100

2

105

4.9

136

6.4

180

1.8

180

2.5

200

2

500

6

926

3


Application:

wind blade,Infrastructure, transportation, sports, medical apparatus, industrial equipment, leisure entertainment. etc.


组 1.jpg
