Carbon Fiber Plate for Civil Engineering Reinforcement

Lica®-CFP series carbon fiber plate is produced by special resin and high performance carbon fiber. The yarn tension keeps evenly and stable. The plate has good endurance and corrosion resistance, excellent anti-fatigue resistance, high strength and convenient construction, light weight and thickness, which make the cross and overlap easier.

market@hitechfrp.com

Inquiry Now

Product Detail

Type	HS Series					HM Series
Model	CFP1.2-100	CFP1.4-50 CFP1.4-100	CFP2.0-50 CFP2.0-100	CFP3.0-50	CFP1.2-100M	CFP1.4-50M CFP1.4-100M	CFP2.0-50M CFP2.0-100M	CFP3.0-50M
Thickness (mm)	1.2	1.4	2.0	3.0	1.2	1.4	2.0	3.0
Width (mm)	100	50/100	50/100	50	100	50/100	50/100	50
Length(m)	50/100	50/100	50/100	50/100	50/100	50/100	50/100	50/100
Tensile Strength，MPa	≥2800					≥2800
Elastic Modulus，GPa	≥160					≥200
Elongation，%	≥1.6					≥1.3
	Customized production available
